LD-FMK-4060 60W Flying Style Manufactured Date And Serial Code
Fiber Laser Marking Machine
Which laser laser power suit me, 20w 30w or 50w?
20w fiber laser marking machine
The most hot sale system by lowest price advantage. Especially for
marking on plastic and hard metals, it occurs perfect results.
Especially suitable for auto parts, packing, kitchenware, hardware,
hand tools, animal tags, bird rings, jewelry marking.
30w fiber laser marking machine
Suitable for work shops and people who needs more power for a large
amount of marking. One upper level then marking towards cutting.
50w fiber laser marking machine
do deep engraving, micro cutting, marking and 3D engraving perfect.
Mostly preferred by gold silver copper jewelry cutting, F 50
creates %40 more effective results according to its competitors.
One of the fastest model in market.
Features:
1). Excellent laser beam quality: Compared with traditional solid laser marking machine, fiber laser
marking machine use base module (TEMOO) output, diameter of focal
spot is less than 20um. Divergence angle is only 1/4 of
semi-conductor pumping Laser. It is special suitable for precision
marking.
2). Maintenance-free, long service life:Small wastage, high stability, not be affected by the outside dirt,
steam and mechanism loosed, can be normal used under the abominable
environment, such as high concussion, high temperature and dust,
etc. using laser diode as the pumping source, totally enclosed type
light path design. mean-time to double failure is over 100 thousand
hours.
3). Fast processing speed:Its processing speed is 2-3 times of traditional laser marking
machine.
4). Low processing cost: Optical-electric transferring efficiency is 30%, power consumption
is less than 200 W, which is only 1/20 of light-pumped solid-state
laser marking machine, greatly saving energy expenditure for long
term usage.
5). Maintenance Free: No need maintenance of laser medium. Do not need adjust or clean
the lens.
Applications:
Widely used in industries of plastic key-press, Silicon Rubber
key-press, communication, electronics, vehicle parts, IT, IC,
precise accessories or metal products, electric appliance, glasses,
watch and clocks, apparatus, or art craft, etc.
Technical parameters:
| Model No. | LD-FMK-4060 Fiber Marking Machine |
| Laser Power | 60W |
| Wavelength | 1064nm |
| Beam quality M2 | <1.5 |
| Adjusting Q frequency | 20—100KHz |
| Marking range (mm) | 100×100 |
| Marking depth | ≤0.1mm |
| Linear speed | ≤9000mm/s |
| Min line width | 0.008mm |
| Min character | 0.3mm |
| Repeat accuracy | ±0.001mm |
| Power supply | 220V±22V/50Hz /7A |
| Overall power consumption | 200W |
| Main machine dimension | 535 mm X435 mm X710 mm |
| Weight of Whole machine | 60KG |
| Control system dimension | Integration |
Installation and training
1.Without sending engineer Manual and video will be sent to you for
training and learning
how to install machine. Internet remove assistance is available
24hs everyday.
2.With engineer Engineer will be sent to your country for one week,
dealing with the installation and training.User need to take care
of tickets, accommodation, food and cooperating with the engineer
we dispatch.
3. If you are here you get 5 days for free training, if you are in
our factory. We will learn you any basic information about the
machine.
After-sales services:
1. International quality certificate, FDA,CE.
2. 100,000 hours lifetime, free maintenance.
3. 24 months warranty against manufacture defect.
4. Engineers available to service machinery overseas.
5. Free training for machine installation and operation.
6. Free samples marking of customer provided.
7. 24 hours technician professional and timely after-sale service.
